Brand: CNCTOPBAOS

Features:

• Size&TravelTable length,width,and height: 6.1″x9.05″x5.11″=155x230x130mm; Travel X-axis: 3.14″=80mm; Travel Y-axis: 2.63″=67mm; Base hole spacing: 4.13″=105mm.
• Max jaw openingMax jaw opening: 2.95″=75mm; One Round scale:1.5mm; Gross weight of the vise: 6.3LBS=2.9KG
• MaterialEquipped with detachable rubber jaw protective sleeve,clamping is more stable,tight,and anti-skid; Thickened aluminum alloy base,with thick and wear-resistant screw rods,ensuring high accuracy and high hardness in the smallest space.
• Hand wheelThe force bar can rotate 360 degrees to adjust the width of the vise clamp,and the handwheel has a marked 0.05mm increment to achieve maximum accuracy,the stroke for one revolution is 1.5mm,A ring=1.5mm; Equipped with 2 rotating crank handles for adjusting the vise from front to back and from left to right, with bolt fixing slots for fixing.
• ApplicationThis cross slide vise is mainly suitable for small mills and drilling machines, and can also be applied to other suitable machine tools, such as drilling machine brackets,desktop drilling machines,woodworking and metal processing etc.

Package Dimensions: 9.9 x 9.4 x 5.9 inches
